HYDRAULIC HOSE

SAE J517 & ISOBARIC SERIES

LET'S FIND YOUR SOLUTION!

SAE J517 series

We offer a wide range of SAE J517 series hose with a variety of pressure ratings, bend radii, and material configurations that meet or exceed the requirements of hydraulic hose specification SAE J517.

THERMOPLASTIC HOSE

SAE 100R7, THERMOPLASTIC HYDRAULIC HOSE

SAE 100R8, THERMOPLASTIC HYDRAULIC HOSE

NON-CONDUCTIVE THERMOPLASTIC HYDRAULIC HOSE

SAE 100R18, THERMOPLASTIC HYDRAULIC HOSE

NON-CONDUCTIVE THERMOPLASTIC HYDRAULIC HOSE

RUBBER HOSE

SAE 100R1 AT, EN 853 1SN, RUBBER HYDRAULIC HOSE

SAE 100R2 AT, EN 853 2SN, RUBBER HYDRAULIC HOSE

SAE 100R4, RUBBER HYDRAULIC SUCTION HOSE

SAE 100R12 MULTISPIRAL RUBBER HYDRAULIC HOSE

SAE 100R13 MULTISPIRAL RUBBER HYDRAULIC HOSE

SAE 100R14, SAE J517 STAINLESS STEEL BRAIDED PTFE

SAE 100R15, MULTI-SPIRAL RUBBER HYDRAULIC HOSE

SAE 100R16, EN 857 2SC, COMPACT RUBBER HYDRAULIC HOSE

SAE 100R17, ISO 18752, COMPACT RUBBER HYDRAULIC HOSE

SAE 100R19, ISO 18752, COMPACT RUBBER HYDRAULIC HOSE

COMPACT RUBBER HYDRAULIC HOSE

COMPACT RUBBER HYDRAULIC HOSE

MULTI-SPIRAL RUBBER HYDRAULIC HOSE


MULTI-SPIRAL RUBBER HYDRAULIC HOSE

ISOBARIC SERIES

Isobaric hoses are designed to have a constant working pressure regardless of the hose size. Our hose is designed and tested to meet requirements of ISO 18752. There is no sacrifice in performance when choosing an isobaric hose as each hose is manufactured to the highest standards and tested to the rigorous conditions that meet or exceed common SAE or ISO standards.

7 MPA / 1000 PSI

21 MPA / 3000 PSI

28 MPA / 4000 PSI

35 MPA / 5000 PSI

42 MPA / 6000 PSI

Not all sizes are stocked at all times. Some specifications may vary. Please inquire about availability. ProPulse reserves the right to make any engineering or material changes at any time to our products for enhancement, performance, and quality.

HYDRAULIC HOSE CATALOG

hydraulic hose & fittings

View all our hydraulic hose & fittings, as well as helpful information including: hose installation and best practices, measuring the length of a crimped hose assembly, chemical resistance and approved fluid media, coupling and adapter torque recommendations, conversion tables, warnings and more.

Frequently Asked Questions

You have questions and we have answers!

SAE 100R1 and SAE 100R2 hoses are versatile for use in construction, agricultural, transportation, forestry, mining, and industrial equipment. However, compact hoses such SAE 100R16 and SAE 100R17 offer greater flexibility in tight spaces on mobile equipment and are more cost effective than the traditional SAE 100R1 and SAE 100R2 hoses.  SAE 100R4 is commonly used for low-pressure hydraulic return or suction lines. High-pressure needs in heavy equipment use SAE 100R12 and SAE 100R13, with SAE 100R15 for ultra-high pressures.

To aid procurement and engineering professionals, the industry has seen a trend away from specific SAE designations on hose, leading to the development of the Isobaric hose line. Isobaric hose is a constant pressure rated hose regardless of the hose diameter. These hoses have close ties to SAE rated hoses and are typically noted to have performance to the ISO 18752 standard.

Hose life is completely dependent on application and environmental factors. According to SAE J1273, the typical shelf life for a rubber hydraulic hose stored out of sunlight and in a controlled environment is approximately 6 years. In ideal storage conditions, such as a climate-controlled environment, this shelf life may be extended. Per SAE, thermoplastic hydraulic hose has an unlimited shelf life.

Hydraulic hoses should be inspected regularly and replaced as soon as signs of wear, cracks, or damage appear. In harsh environments, more frequent checks may be necessary.

This is not recommended. The safest and most reliable approach is to replace the damaged hose as soon as possible. Keeping spare hoses on hand and performing regular maintenance checks can help prevent unexpected failures and safety risks.

Signs your hydraulic hose needs replacement include visible damage (cracks, bulging, kinks), leaks, softness or brittleness, and unusual noise. Exposure to UV or extreme temperatures can also cause much faster hose degradation. Hoses aging past 6 years old or under continual high pressure may need replacement. Regular inspections help catch issues early.

· 25 feet

· 50 feet

· 100 feet

These options provide flexibility in choosing the right hose length based on the specific requirements of your pressure washing tasks, whether you need a shorter hose for small, residential jobs or a longer hose for commercial or extensive property cleaning.

Although this is a very subjective topic depending on the application, in many cases the most flexible hydraulic hoses are SAE 100R7 and SAE 100R18. Both are thermoplastic hoses, offering excellent flexibility and resistance to abrasion and chemicals, as well as superior UV and ozone protection when compared to rubber hose equivalents. SAE 100R7 and SAE 100R18 are commonly used in low to medium-pressure applications and are ideal for tight bends and high maneuverability in construction, agriculture, transportation and industrial machinery.

The strongest hydraulic hoses are those with spiral wire reinforcement, like SAE 100R12, SAE 100R13, SAE 100R15 capable of handling pressures up to 6,000 psi. These hoses are used in heavy-duty applications for maximum strength and durability. As the industry moves to the Isobaric line, these hoses are commonly referred to as 4000psi, 5000psi, or 6000psi hoses.
