700 SERIES
THERMOPLASTIC Hydraulic Hose
Hose Construction:
- Inner Tube: Oil resistant thermoplastic
- Reinforcement: One or two layers of high tenacity yarn
- Cover: Oil resistant thermoplastic elastomer with high ozone and abrasion resistance (-2 and -3 are smooth cover; -4 through -8 are matte textured cover)
Main Applications:
- Medium pressure hydraulic application that requires high flexibility, tight bend radius and good abrasion resistance to weather and ozone
- Agriculture, construction, forestry and mobile equipment; fork trucks; general hydraulic; hydraulic tools, lubrification systems; marine steering; snow plow
Temperature Range:
- -40°F / +212°F
- -40°C / +100°C
Fully Meets or Exceeds the Following Specifications:
- SAE 100R18 / 100R7* (sizes -2 through -6)
- SAE 100R7 (size -8)
Note:
- Not all sizes stocked at all times. Some specifications may vary. Please inquire about availability. ProPulse reserves the right to make any engineering or material changes at any time to our products for enhancement, performance, and quality.
- Made in the USA.
*This hose is dual branded—sizes -2 through -6 meet or exceed all SAE 100R18 requirements.
Benefits of Thermoplastic Hydraulic Hose:
- Abrasion resistant matte cover
- Unlimited shelf life
- High impulse life
- No pin holes
- 20% lighter than rubber hose
- UV, ozone and chemical resistance
- Made in the USA
