800 Series
thermoplastic hydraulic hose
Hose Construction:
- Inner Tube: Oil resistant thermoplastic
- Reinforcement: Aramid fiber braid
- Cover: Oil and weather resistant thermoplastic elastomer with
high ozone and abrasion resistance (-3 is smooth cover; -4
through -8 are matte textured cover)
Main Applications:
- High pressure hydraulic applications that require high
flexibility, tight bend radius and good abrasion, weather and
ozone resistance - Agriculture, construction, forestry and mobile equipment;
fluid handling; machine and rescue tools; marine steering
Temperature Range:
- -40°F / +212°F
- -40°C / +100°C
Fully Meets or Exceeds the Following Specifications:
- SAE 100R8
Note:
- Not all sizes stocked at all times. Some specifications may vary. Please inquire about availability. ProPulse reserves the right to make any engineering or material changes at any time to our products for enhancement, performance, and quality.
- Made in the USA.
Benefits of Thermoplastic Hydraulic Hose:
- Abrasion resistant matte cover
- Unlimited shelf life
- High impulse life
- No pin holes
- 20% lighter than rubber hose
- UV, ozone and chemical resistance
- Made in the USA
